Technical Data Sheet
| Materials | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| PN 0 | PR 0 | P 10 | P 20 | P 25 | PK 0 | PK 10 | PK 20 | M 0 | M 10 | MS 10 | |
| textile tape | polyester | ||||||||||
| sewing thread | polyester | – | – | ||||||||
| coil | polyestermonofilament | – | – | ||||||||
| teeth | – | polyacetal | brass | ||||||||
| top stop | polyester | aluminium | polyacetal | brass | |||||||
| bottom stop | polyester | aluminium | polyacetal | brass | |||||||
| open end fitments | fine zinc pressure cast alloy | polyacetal | fine zinc pressure cast alloy | ||||||||
| slider | fine zinc pressure cast alloy | ||||||||||
| Technical data (in N) | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| PN 0 | PR 0 | P 10 | P 20 | P 25 | PK 0 | PK 10 | PK 20 | M 0 | M 10 | MS 10 | |
| puller attachment (only with metal puller) | 70 | 80 | 200 | 250 | 300 | 70 | 200 | 250 | 80 | 200 | 200 |
| strength of indivisible zipper (closed end) | 35 | 60 | 80 | 100 | 140 | 35 | 60 | 100 | 60 | 80 | 80 |
| strength of attachment of top stops | 50 | 70 | 90 | 110 | 130 | 50 | 90 | 110 | 70 | 90 | 90 |
| lengthwise strength of the box (unit of open-end part) | – | 60 | 90 | 120 | 150 | 40 | 90 | 120 | 70 | 90 | 90 |
| resistance of chain to lateral load | 300 | 350 | 600 | 800 | 900 | 250 | 400 | 600 | 425 | 500 | 500 |
| resistance of open-end fitment to lateral load | – | 70 | 90 | 120 | 160 | 40 | 90 | 120 | 70 | 90 | 90 |
| Measurements of zippers (in mm) | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| PN 0 | PR 0 | P 10 | P 20 | P 25 | PK 0 | PK 10 | PK 20 | M 0 | M 10 | MS 10 | |
| total width of teeth | 4,2 | 4,2 | 6,5 | 8,5 | 10,5 | 4,5 | 5,8 | 8,7 | 4,5 | 6 | 6 |
| single tape width (tolerance +/- 0.5 mm) | 12 | 12 | 16 | 20 | 20 | 14 | 14 | 18 | 12 | 14 | 14 |
| total width of zipper (tolerance +/- 1 mm) | 24 | 24 | 32 | 40 | 40 | 30 | 30 | 38 | 25 | 30 | 30 |
| Materials | ||||||
|---|---|---|---|---|---|---|
| PN 5 | M 0 polished | M 10 polished | M 20 polished | M 20 | M 0 (cotton) | |
| textile tape | polyester | cotton | ||||
| sewing thread | polyester | – | ||||
| coil | polyestermonofilament | – | ||||
| teeth | – | brass | ||||
| top stop | polyester | brass | ||||
| bottom stop | polyester | brass | ||||
| open end fitments | fine zinc pressure cast alloy | – | ||||
| slider | fine zinc pressure cast alloy | |||||
| Technical data (in N) | ||||||
|---|---|---|---|---|---|---|
| PN 5 | M 0 polished | M 10 polished | M 20 polished | M 20 | M 0 cotton | |
| puller attachment (only with metal puller) | 70 | 80 | 200 | 250 | 250 | 80 |
| strength of indivisible zipper (closed end) | 35 | 60 | 80 | 100 | 100 | 60 |
| strength of attachment of top stops | 50 | 70 | 90 | 110 | 110 | 70 |
| lengthwise strength of the box (unit of open-end part) | – | 70 | 90 | 120 | 120 | 70 |
| resistance of chain to lateral load | 350 | 425 | 500 | 700 | 700 | 300 |
| resistance of open-end fitment to lateral load | – | 70 | 90 | 120 | 120 | 70 |
| Measurements of zippers (in mm) | ||||||
|---|---|---|---|---|---|---|
| PN 5 | M 0 polished | M 10 polished | M 20 polished | M 20 | M 0 (cotton) | |
| total width of teeth | 4,9 | 4,55 | 5,8 | 7,5 | 7,5 | 4,5 |
| single tape width (tolerance +/- 0.5 mm) | 12 | 12 | 14 | 17 | 17 | 12 |
| total width of zipper (tolerance +/- 1 mm | 24 | 26 | 30 | 35 | 35 | 25 |
Rights to make technical revision reserved.
With a few exceptions, our zippers are certified according to STANDARD 100 by OEKO-TEX® product class II. For some articles and a selected range of colors and sliders, we offer certification according to STANDARD 100 by OEKO-TEX ® product class I too. Please contact your account manager for more information.
